Description

Burner gas boiling range made of AISI 304 stainless steel, 20/10 mm thickness top. Top grids and burners in enamelled cast iron. Valve controlled removable burners with double crown burner cap. Pilot light and thermocouple. Pressed and sealed burner recess. Gas static oven in AISI 430 stainless steel with removable stainless steel guides and thermostat, useful for 2/1 GN containers. Side cabinet with door, equipped with tray guides useful for 4 x GN 1/1 containers

Function Features

•  Gas cooking top equipped with n. 6 open burners.

• n. 4 open burners with double-crown burner cap diam. 110 mm rated 6.5 kW with continuous power regulation from 6.5 to 1.9 kW.

• n.2 open burners with single-crown burner cap diameter 80 mm rated 4 kW with continuous power regulation from 4 to 1.3 kW.

• Burners coupling in ceramic material for easy extraction.

• Burners and cast iron pan grids easily removable and washable.
• Burner Venturi tube with a innovative shape that guarantees an optimal combustion and safeguards the injector from plugging.
• The double crowned burner and the particular inclination of the flame ensure a better uniformity and thermal distribution on thebottom even of large pots.
• Gas static oven rated at 6 kW.
• Oven capacity: GN 2/1 (or GN 1/1) containers, on demountable stainless steel tray rack with three height levels.
• Cooking oven temperature control from 80°C to 300°C.
• Oven heating by burner with pilot light, thermocouple and piezoelectric ignition.
• Side cabinet made of AISI 304 stainless steel, door, stainless steel tray guides useful for 4 x GN 1/1 containers. With door.
• Hinged door, right opening, with sandwich panel, made in AISI 304 stainless steel, grip directly pressed on the door plate, easy to
  clean.
• Pre-set appliance for installation freestanding on feet.
